Safe HVAC Scent Diffuser System 5000 Cubic Meters for Industrial Cleaners

Product Categories

Charm Aroma Environmental Technology Co., Ltd.

Contact Now

Name: Safe HVAC Scent Diffuser System 5000 Cubic Meters for Industrial Cleaners
Brand: CharmAroma
Price: 1 USD

Brand Name : CharmAroma

Model Number : CH123

Certification : CE and more

Place of Origin : GuangDong, China

MOQ : 4 Pieces

Price : EXW USD106 per Piece

Payment Terms : T/T, Paypal and more

Supply Ability : 1000 Pieces per Month

Delivery Time : Within 5-15 Working Days

Packaging Details : Polybag + Foam + Inner Box + Master Carton

Description : HVAC Scent Air Misting System

Power : 26W

Essential Oil Consumption : 0.33ml ~ 6.2 ml /H

Color : White/customized

Usage : Wall mounted or Connect to HVAC or Stand-alone

Memory Battery : Have

Contact Now

5000 Cubic Meters HVAC Scent Air Misting System for Industrial Cleaners

HVAC Scent Air Misting System Introduction

Technology	CH123 HVAC Scent Air Misting System adopts the cold air diffusion technology and there is no trace left behind in the air.
Usefulness	This scent machine is mainly for the commercial scent marketing, which could Destroy the heavy smoking bad odor, food odors, attacks the various odors from the pets and help to destroy unpleasant smells in such an environment, reduce bad smelling of solid surfaces near toilets or urinals and more. So that to leave a good impression for all your clients, makes good moods and a cleaner and fresher environment for all of us, let all of us feel healthier and more pleasant.
With lock	Its front door has the lock function, after we set well the scent machine working time and the essential oil intensity, we could lock the door to avoid other people to touch the essential oils, bottle and the spare parts in the storage room.
Installation ways	Beautiful looking could blend everywhere. It is sleek, and could standalone or wall mounted on the wall, also it is perfect for connecting with the HVAC system.
Coverage	CH123 HVAC Scent Air Misting System is our new item for large spaces up to a maximum 5000 cubic meters.

Technical Data

Model No.	CH123 HVAC Scent Air Misting System
Shell Material	Anticorrosion Metal
Color	White , Black
Dimension	390H X 270W X 185D mm
Net Weight	7.5kg
Standard Packing	4 Pieces / Master Carton
Power Supply	110-220V/ 26W
Coverage	3000-5000m3
Installation Way	Connect HVAC /Wall Mounted / Standalone
Essential Oil Bottle Capacity	1000ml in Aluminum
Essential Oil Consumption	0.33ml ~ 6.2 ml /H(+/-5%)
Noise Level	< 50dba
Atomizer Material	Aluminum alloy
Origin	Made in China
Technology	Cold air diffusion technology

Accessory

Operation Steps

Pease read the user manual or see our video demo for the first time using.

Step 1: use the key to open the machine door,
Step 2: Fill maximum 1000ml essential oil into the empty oil bottle and put it back into the scent machine
Step 3: connect the air tube with the HVAC system and the scent machine

Tips of connect to HVAC system

Confirm the position of the machine as shown as below photo.
Connect the air tube into the HVAC system. The hole of the tube must be higher than the scent machine, and the direction of tube should be downwind.
After confirming the position of the tube, punch the hole and fix the air tube in the hole with a tie wrap.

Step 4:Plug the diffuser to electric socket
Step 5: Press the 4 keys to set the local time same as your country
Step 6: Press the 4 keys to set the working time and the intensity
Step 7: Lock back the scent machine door. Done, please enjoy your scenting world.

Safe HVAC Scent Diffuser System 5000 Cubic Meters for Industrial Cleaners
