Connect to HVAC System Ambient Scenting Machine with 1000ml Essential Oil Bottle for 2000 CBM
Description of Ambient Scenting Machine
CH122 ambient scent machine is working with low noise which is less than 42DBA.
It could work with AC system so that the dry scent mist could follow the air flow through the HVAC system into the every room to be scented. Also, we could use it as a stand-alone or a wall mounted unit as well so that you could put it anywhere just sure that there is a power point nearby.
This kind of scent diffuser is adopted the cold-air diffusion technology and designed to work with only oil-based oil and with no water.
And it has a 1000ml big aluminum oil bottle so that no need to refill the oil all the time.
It is easy to install with the HVAC system, and we will provide all the accessories, steps as following:
1: Confirm the position of the machine as shown as the photo in our user manual.
2: Connect the air tube into the HVAC system. The hole of the tube must be higher than the scent machine, and the direction of tube should be downwind.
3: After confirming the position of the tube, punch the hole and fix the air tube in the hole with a tie wrap.
Usefulness
The CH122 scent machine is to use as the stand-alone or wall mounted type, it is perfect to connect to HVAC system so that the dry nanoparticle scent mist could be delivered to every areas which are connected by the HVAC system. It could not only uses for industry scent marketing, but also could use for homes. The good smelling could remove the bad odor, could upgrade your brand and increase your selling and more.
Product Data
| Model No. | CH122 |
| Shell Material | Durable Metal |
| Color | White , Black |
| Dimension | W240 by D150 by H370mm |
| Net Weight | 5.5 KG |
| Standard Packing | 6 pieces per one master carton |
| Power Supply | DC12V 14W |
| Coverage | from1000 to 2000 cubic meters |
| Installation Way | Connect to HVAC system, Wall Mounted or Stand-alone |
| Cartridge | 1000ml Aluminum Oil Bottle |
| Essential Oil Consumption | From 0.2ml to 3.8 ml per hour |
| Noise Level | Less than 42dba |
| Warranty | 1 Year |
| Country of Origin | Made In China |
| Application | Hotels, Office Building, Lobby, Cinemas and more |
Excellence Performance
| 1 | Build in fan | make the much more evenly aroma dry mist of home or commercial places |
| 2 | Lockable | Auto locks function of setting program and with lock for the machine to protect the oil bottle and the setting program |
| 3 | Large Coverage | A maximum up to 2000 cubic meters |
| 4 | 3 in 1 Installation Way | Connect to HVAC system, wall mounted and stand freely |
| 5 | Smart Setting | 19 intensity setting options, 15 options for the working day setting, 5 groups working events, auto running. |
Product Accessory
| 1000ml Empty Oil Bottle | 1 piece | User Manual | 1 piece |
| Screws and Connector | 4 sets | Keys | 2 pieces |
| Spare Atomizing Core | 1 piece | AC Power Adapter | 1 piece |
| Air Tube | 1 piece | Air Tube Connector | 1 piece |
